The ZEISS LRP S3 first focal plane riflescopes provide the best-in-class total elevation travel. In the world of long-range rimfire competition, the little 22 LR cartridge is frequently pushed beyond its intended limits. In turn, the capabilities and performance of the riflescope are tested at the extreme - with a key limiting factor for many scopes being sufficient elevation travel.
Zeiss LRP S3 636x56 (MOA) ZF-MOAi Reticle offers the best solution for medium to extreme long-range shooting. The 6x-36x magnification range is combined with a 32 MRAD elevation turret which supports more precise shot placements.
SPECIFICATIONS:
Magnification: 6 – 36 ×
Effective lens diameter: 56 mm
Light transmission: 90%
Exit pupil diameter: 8.8 – 1.6 mm
Twilight factor: 17.7 – 44.9
Field of view at 100 m (yds): 6.8 – 1.1 m (20.4 – 3.3 ft)
Objective viewing angle: 3.9° – 0.6°
Diopter adjustment range: + 3.0 | − 3.0 dpt
Eye relief: 80 – 90 mm (3.0 – 3.5 ")
Parallax setting: 10 m – ∞ (10.9 yds – ∞)
Vertical adjustment range at 100 m: 32.0 MRAD | 110 MOA
Lateral adjustment range at 100 m: 14.6 MRAD | 50 MOA
Adjustment per click at 100 m: 0.1 MRAD | 0.25 MOA
Centre tube diameter: 34 mm
Eyepiece tube diameter: 45 mm
Objective tube diameter: 65 mm
MPN: 522685-9917-090
