ZEISS
ZEISS VICTORY RF 8x54
No reviews
Regular price
$4,199.99
Title
ONLINE ORDERS ONLY
The ZEISS VICTORY RF 8x54 binocular laser rangefinder system incorporates a laser with an integrated real-time ballistics computer and on-board weather station. The consideration of all relevant factors coupled with user-based customization via the ZEISS Hunting App further ensures precisely placed shots from 10-2,500 yards away - time after time. The laser signals and atmospheric data received is computed within nano seconds to give you the appropriate, and accurate, shooting solution from a single press of a button.
SPECIFICATIONS:
Magnification: 8 ×
Effective lens diameter: 54 mm
Exit pupil diameter: 6.8 mm
Twilight factor: 20.8
Field of view at 1,000 m (yds): 120 m (360 ft)
Subjective viewing angle: 54° Ww
Close focusing distance: 3.5 m (11.5 ft)
Diopter adjustment range: − 4.0 / + 4.0 dpt
Exit pupil distance: 14 mm
Pupil distance: 58.5 – 76 mm
Lens type: FL
Prism system: Abbe-König
LotuTec / Nitrogen filled: + / +
Water resistance: 100 mbar
Measuring range: 10 – 2,300 m (11 – 2,500 yds )
Measuring accuracy: ± 1 – 600 / ± 0.5 % > 600 m (yds)
Measuring duration: < 0.3 Sec
Laser wavelength: 905 nm
Laser beam divergence: 1.6 × 0.5 nm
Battery: 1 × 3V Type CR 2
Battery life at +20°C: > 2.500 ×
Operating temperature: − 30°C / + 63°C (− 22°F / + 145°F)
Length: 195 mm (7.7 ")
Width at an interpupillary distance of 65 mm: 141 mm (5.6 ")
Weight: 1,095 g (38.6 oz)
Effective lens diameter: 54 mm
Exit pupil diameter: 6.8 mm
Twilight factor: 20.8
Field of view at 1,000 m (yds): 120 m (360 ft)
Subjective viewing angle: 54° Ww
Close focusing distance: 3.5 m (11.5 ft)
Diopter adjustment range: − 4.0 / + 4.0 dpt
Exit pupil distance: 14 mm
Pupil distance: 58.5 – 76 mm
Lens type: FL
Prism system: Abbe-König
LotuTec / Nitrogen filled: + / +
Water resistance: 100 mbar
Measuring range: 10 – 2,300 m (11 – 2,500 yds )
Measuring accuracy: ± 1 – 600 / ± 0.5 % > 600 m (yds)
Measuring duration: < 0.3 Sec
Laser wavelength: 905 nm
Laser beam divergence: 1.6 × 0.5 nm
Battery: 1 × 3V Type CR 2
Battery life at +20°C: > 2.500 ×
Operating temperature: − 30°C / + 63°C (− 22°F / + 145°F)
Length: 195 mm (7.7 ")
Width at an interpupillary distance of 65 mm: 141 mm (5.6 ")
Weight: 1,095 g (38.6 oz)
SKU: 525648-0000-000
