The EL RANGE is the latest demonstration of the innovativeness that lies at the heart of SWAROVSKI OPTIK. It combines SWAROVISION technology with precise range measurement. Spot game quickly and accurately thanks to the precision and
edge-to-edge sharpness of SWAROVISION technology. The EL Range can be configured to suit your specific needs and you can transfer your own ballistics data, along with air pressure and temperature readings, allowing you to make an accurate assessment of every hunting situation. The innovative tracking assistant helps you to narrow down the area where your last shot hit the target.
Accuracy can also mean versatility. The EL Range 8x42 binoculars are ideal for numerous viewing opportunities right up to twilight. Their expansive field of view and large exit pupil ensure optimum comfort during observation.
RANGEFINDER
The binoculars combine state-of-the-art optics with precise measuring functions.
The integrated tilt indicator with a unique angle shot program displays either the adjusted shooting distance or the angle. The EL RANGE gives you precise measurements from a distance of 10 meters (10.9 yards).
PERSONALIZED BALLISTICS
Use the smartphone app to configure the binoculars to your specific needs and individual ballistics data. Based on this and atmospheric data such as air pressure and temperature, it helps you to shoot with even greater precision because, along with the adjusted shooting distance, it also gives you the number of clicks needed for your rifle scope.
TRACKING ASSISTANT
The integrated Tracking Assistant makes it much easier to track your prey by guiding you to where you fired your last shot. You can opt to use this program via your phone or your EL Range.
SPECIFICATIONS
OBJECTIVE
Magnification: 8x
Effective objective lens diameter: 42 mm
Exit pupil diameter: 5.3 mm
Exit pupil distance: 19 mm
Field of view at m/1,000 m / ft/1,000 yds: 419 ft/1000 yds
Field of view degrees: 8 °
Field of view with eye glasses (degrees): 8 °
Field of view apparent: 61 °
Shortest focusing distance: 16.4 ft
Diopter adjustment: -7 to +5 dpt
Light transmission: 90 %
Pupil distance: 2.2-2.9 in
Twilight factor acc. to DIN-58388: 18.3
SIZE & WEIGHT
Lenght: 6.8 in
Width: 5.3 in
Height: 3.1 in
Weight without batteries: 32.8 oz
MEASUREMENT
Measuring range: 10 - 2200 yd
Measuring accuracy in yds./ m.: ± 1 yd
Measuring time: ≤ 0.5 s
Angular measurement: ± 90 °
Laser: Class 1 EN/FDA
Units: Yard / Meter
Life cycle 2,000 measurements
CR2 Battery
ENVIRONMENT & CONDITIONS
functional-temperature-mechanically-electronically
-13 to +131 / +14 to +131 °F
SUPPLIED WITH
- WITHOUT HEADREST
- UCS universal comfort strap
- FSB functional sidebag
- Eyepiece covers
- Objective lens covers
- Soap & brush kit
- Microfiber cloth
- Strap loop connector
- Cover for steel rings (when detaching the objective lens cover)
- BT tool
